Feature: 1. AC input range can be selected by switch, very flexible and convenient foryou to use 2. The product after withstand 5G vibration test, come with LED indicator for booting 3. 100% full load aging test, the maximum working temperature can reach 70℃, very durable 4. 75W switching power supply possess high efficiency, long life and high reliability 5. LED switching power supply is made of good-quality aluminum and PCB material, possess high reliability Specification: Item Type: LED Switching Power Supply Material: Aluminum and PCB Purpose: Power supply function Detailed Parameters (12V and 24V models): 1. Output Value: DC Voltage: 12V / 24V Rated Current: 6A / 3.2A Current Range: 0~6A / 0~3.2A Rated Power: 75W / 75W Ripple and Noise (maximum): 120mVp-p / 150mVp-p Voltage Adjustment Range: 10.2 ~ 13.8V / 21.6 ~ 28.8V Withstand Voltage: ±1.0% / ±1.0% Line Adjustment: ±0.5% / ±0.5% Load Regulation: ±0.5% / ±0.5% Setting, Rise Time: 500ms, 30ms / 230VAC; 500ms, 30ms / 115VAC (full load) Holding Time (typical value): 60ms / 230VAC; 12ms / 115VAC (full load) 2. Input Value: Voltage Range: 85~264VAC; 120~373VDC Frequency Range: 47 ~ 63Hz Efficiency (typical value): 89% / 90% AC Current (typical Value): 1.4A / 115VAC, 0.85A / 230VAC Inrush Current (typical Value): 50A / 230VAC Leakage Current: <0.75mA 240VAC 3. Protection: Overload: 110~150% of rated output power; Protection Type: Hiccup mode, automatic recovery after the fault condition is eliminated 4. Environment: Working Temperature: -20~+70℃ Working Humidity: 20~90%RH non-condensing Storage Temperature and Humidity: -40~+85℃, 10~95%RH Temperature Coefficient: ±0.03% ℃ (0 ~ 50℃) Vibration: 10 ~ 500Hz, 5G, 10 minutes /1 cycle, 60 minutes each along the X, Y, and Z axes 5. Safety and EMC: Safety Standards: EN60950-1, EN60335-1, EN61558-1, approved. Withstand Voltage: I /P-0 /P: 1.5KVAC I /P-FG: 1.5KVAC 0 /P-FG: 0.5KVAC Isolation Resistance: I /P-O /P, I /P-FG, 0 /P-FG: 100M Ohms / 500VDC /25℃ / 70% RH 6. How to Use: Can be used when connected to the current line, L is connected to the live wire, N is connected to the neutral line, +v is connected to the output positive pole, -v is connected to the output negative pole, the white regulator can realize the fine adjustment of the voltage, and the ground wire identification is the ground wire interface. . Package List: 1 x LED Switching Power Supply
